About Chi-Pad
Chi-Pad is a patented (GB 2559905) component allowing rain screen installations to benefit from the low thermal conductivity values associated with aerogel insulants (synthetic amorphous silica) to reduce thermal bridging within the design.
Chi-Pad is easily attached to the rear face of the Helping Hand Bracket prior to installation on the facade. The Chi-Pad has a self adhesive strip with peel off release paper.
Features & Benefits
Chi-Pad:
- provides an enhanced thermal barrier between the external cladding and inner components of the assembly positioned closest to the building external wall
- offers superior thermal performance at reduced profile thickness compared to other insulation solutions
- is hydrophobic repelling liquid water
- is breathable allowing vapour to pass through helping to control corrosion under insulation
Applications
The Chi-Pad can be attached to Helping Hand Brackets to provide an enhanced thermal barrier.
Specification
Insulant
| Insulant | Specification/Method | Value/Result | |
|---|---|---|---|
| Thickness | 10mm | ||
| Colour | Maroon | ||
| Density | 180 Kg/m 3 |
Testing
Chi-Gasket
| Chi-Gasket | Specification/Method | Value/Result | |
|---|---|---|---|
| Reaction to fire (cage) | Small gasket exclusion | ||
| Hygrothermal performance | ETAG 004 2013 • Heat Rain 80 cycles • Heat Cold 5 cycles | No visual deterioration observed | |
| Wind Load Testing | Section 11 CWCT standard | No detraction to serviceability | |
| Wind safety | Section 12 CWCT standard | Factor 1.5 x service load |
Insulant
| Insulant | Specification/Method | Value/Result | |
|---|---|---|---|
| Thermal conductivity | ISO 8301:1991 /BS EN 12667:2001 | 0.018 W/Mk | |
| Reaction to fire | EN 13501-1:2007 | A2-s1,d0 |
Insulant
| Insulant | Specification/Method | Value/Result | |
|---|---|---|---|
| Thermal conductivity | ISO 8301:1991 /BS EN 12667:2001 | 0.021 W/Mk | |
| Thermal resistance | ISO 8301:1991 /BS EN 12667:2001 | 0.494 m 2 K/W | |
| Reaction to fire | BS 476-6:1989 & BS 476-7:1997/EN 13501-1:2007 | Class 0 / B-s1,d0 |
Datasheets
Download our Chi-gasket 018 Brochure
To ensure you have the latest version of this document call 01925 860 999.
Download our Chi-gasket 021 Brochure
To ensure you have the latest version of this document call 01925 860 999.
